Feature for Solar Panel:

Quantity: 8 Pcs

Solar Panel Model: arc mono RT71-450M

Rated Maximum Power (Pmax): 450W

Power Tolerance Range: 0~+5W

Open Circuits Voltage (Voc): 49.3V

Peak Voltage (Vmp): 41.5V

Short Circuit Current (Isc): 11.6A

Peak current (Imp): 10.85A

Max System Voltage: 1500V

Max Series Fuse Rating: 20A

Weight: 25Kg

Module Application: Class A

Dimension (mm): 2094 * 1038 * 35 mm

Efficiency: 20.7%

All technical data at standard test condition: Am 1.5 E=1000W/m3, Tc=25°C

Feature for Inverter:

• Inverter Model Type: 3200VA
• Inverter Model: ARC 3000-24
• Rated Power: 3200W
• DC Input: 24VDC ,148A
• AC Output: 230VAC, 50Hz ,13.9A, 1 ɸ
• AC Charger Mode
• AC Input: 230VAC, 50Hz ,20.0A, 1 ɸ
• DC Output: 27 VDC
• Max.20A: 60A
• Solar Charger Mode (MPPT): MPPT 100A
• Max PV Input Power: 3500W
• Operating Voltage Range (MPPT): 60~450VDC
• Max Solar Voltage Range (Voc): 500VDC
• Communication: USB/RS232/BMS
• Weight (NT): 5.5Kg
•


Feature for Battery:

• Battery Model: ARC-12150
• Rated Capacity (25°C): 1hr, 95.6A, 1.60V/Cell
• Cycle Use: Voltage 14.4V~15.0V at 25°C
• Standby Use: Voltage 13.5V~13.8V at 25°C
• Weight: 41.41±0.10 kg
• Terminal: Silver Coated Copper, M8

Battery cable Black & Red (3 Meters):

• Nominal Cross sectional Area of Conductor(Core x mm2): 1 x 16RM
• No. of strands & diameter of wire (nos./mm): 128/0.40
• Nominal thickness of insulation (mm): 2
• Approx. Overall diameter: 12

Lug 16RM (4 Pcs):

Model/Specs: 16RM, 8mm Hole Diameter

MC-4 Connector (1 Pair):

Model/Specs: MC-4 Connector (4.3-6.6mm)

Panel Structure 1 Set:

Model/Specs: For 8 Pcs Solar Panels , Material: Mild Steel or Aluminum

Warranty:

Solar Panel: Output 20 Years

Battery: 12 Months

Solar Inverter: 18 Months
