General Information: |
|
| Starting System | Electric and Recoil Start |
| Petrol/Octane Consumption at 100% Load | 2.8 Liter |
| Petrol/Octane Consumption at 50% Load | 1.6 Liter |
| LPG Consumption at 100% Load | 3.5 Liter |
| LPG Consumption at 50% Load | 1.75 Liter |
| Fuel Tank Capacity | 25 Liter |
| Fuel Option | Gasoline/LPG |
| Noise level from 7 meters distance at full load | 75dB |
| Continuous Duration of operation at Rated load (hour) | 9h |
|
Technical Parameters |
|
| Maximum Output (Gasoline) | 5.5 KW |
| Rated Output (Gasoline) | 5 KW |
| Maximum Output (LPG) | 5 KW |
| Rated Output (LPG) | 4.4 KW |
| Rated Voltage | 230 Volt |
| Rated Current | 21.7 Ampere |
| Battery Rating | 12 volt, 10 Ah |
|
Engine : |
|
| Engine Type | Single cylinder, 4-Stroke(OHV) |
| Engine Model | EX190F |
| Displacement | 420 CC |
| Engine Oil Capacity | 1.1 Liter |
| Engine Oil Grade | 10W30 |
| Cooling System | Air-Cooled |
| Engine Power | 15 HP |
| Engine RPM | 3000 |
| Ignition System | Non-Contact |
|
Alternator: |
|
| Alternator type | 100% Copper |
| Voltage Regulator | AVR |
| Number of phases | Single |
| Power Factor | 1 |
| Frequency | 50 Hz |
| Insulation Class | F |
| Protection System | AC Circuit Breaker and Low Oil Protection |
| Dimension: | 690mm*515mm* 600mm |
| Net Weight: | 70 Kg |
Warranty Information(Without
Consumable Items)
- Main Parts: 1 Year
- Spare Parts: 1 Year
- After Sales Service: 1 Year
Note: This warranty does not cover any damage due to accident, electricity fault, natural causes or negligence. And Authority keeps the power to change, expend, correction, stop or cancel the warranty period without any prior notice.
- Dual Fuel System- Can use both petrol and LPG.
- Electric and Recoil Start.
- Automatic voltage regulator (AVR).
- Wheels and Handles for easy moving.
- Digital Display for Voltage, Frequency, and Time.
- Stable output.
- Low noise generator.
- Low fuel consumption.
