Galvatron 50KVA - CN
- High-performance 4-stroke diesel engine
- Efficient water-cooled cooling system for reliable operation - Turbocharged engine for enhanced power and fuel efficiency - High overall efficiency of up to 89.30% - IP23 protection for safe and dependable operation - Integrated ventilation system with cooling fan for optimal heat dissipation |
|
Prime Power KVA/KW
|
50KVA/40 KW
|
| Stand by Power KVA/KW | 55 KVA/44 KW |
| Overall Dimension (mm) | 2300*1000*1165 |
| Overall Weight (Canopied) | 1120 kg |
| Noise (dB) | 75 |
| Engine | |
| Brand | WEICHAI |
| Model | WP4.1D66E200 |
| Type of Engine | 4 stroke, water-cooled |
| Number of Cylinders | 4 |
| Governing | Electronic |
| Bore/Stroke (mm) | 105*118 |
| Displacement (L) | 4.1 |
| Compression Ratio | 17.5:1 |
| RPM | 1500 |
| Cooling System | Water-cooled |
| Turbo Charger | √ |
|
Specific Fuel Consumption
Liters/hour:
| |
|
110% Load
|
17.5
|
|
100% Load
|
15.7
|
|
75% Load | 12 |
| 50% Load | 8.4 |
| Weight of Engine (Kg) | 400 |
| Fuel Tank Capacity (L) | 80 |
| Engine oil capacity (L) | 13 |
| Coolant Capacity(L) | 12.2 |
|
Alternator (Generator):
| |
|
Brand
|
WATTEK
|
| Model | WHI224E |
| Type | Self-excited, Brushless |
| Rated Output Voltage | 400V |
| Frequency | 50 Hz |
| Number of Phases and Wires | 3 Phases, 4 Wires |
| Power Factor (Cos Φ) | 0.8 |
| Ventilation | with a cooling fan |
| Protection Class | IP23 |
| Insulation Class | H |
| Max Voltage Regulation | ±1% |
| Efficiency | 89.30% |
| AVR | SX460 |
|
Control System
| |
|
Brand
|
SMARTGEN
|
| Model | HGM6110 |
| Standard meters (what type of data will show?) | Genset output/genset
voltage/battery voltage /fuel capacity/engine speed/engine temperature/running time etc. |
|
Standard Protection
Function:
| |
| Engine Protection | 1.Stop for over speed
2. Alarm for low/high battery voltage3.Low oil pressure 4.Low battery voltage 5. High Coolant temperature 6. Fail to start/Cranking fail 7. Sensor faill |
|
Alternator Protection
|
1.Over Voltage2.Over
current 3.Over frequency 4. Voltage signal lost 5.Under frequency |
|
Genset Protection
|
1.Programmable I/O signal
2.Emergency stop |
Warranty Information:
- Main Parts: 1 Year
- Spare Parts: 1 Year
- After Sales Service: 1 Year
The battery is not included in the warranty.
Note: This warranty does not cover any damage due to accident,
electricity fault, natural causes or negligence. And Authority keeps the power
to change, expend, correction, stop or cancel the warranty period
without any prior notice.
– High-performance 4-stroke diesel engine for reliable, fuel-efficient, and long-lasting performance.
– Efficient water-cooled cooling system ensuring stable operation under continuous and heavy-duty conditions.
– Turbocharged engine delivering enhanced power output with improved fuel efficiency.
– High overall efficiency of up to 89.30% for optimized energy use and reduced operating costs.
– IP23 protection ensuring safe and dependable operation in industrial environments.
– Integrated ventilation system with cooling fan for effective heat dissipation and improved system reliability.
– Efficient water-cooled cooling system ensuring stable operation under continuous and heavy-duty conditions.
– Turbocharged engine delivering enhanced power output with improved fuel efficiency.
– High overall efficiency of up to 89.30% for optimized energy use and reduced operating costs.
– IP23 protection ensuring safe and dependable operation in industrial environments.
– Integrated ventilation system with cooling fan for effective heat dissipation and improved system reliability.
