• WD4-TS43-DL220 (1.09m) Smart WD4-TS43-DL220 (1.09m) Smart WD4-TS43-DL220 (1.09m) Smart WD4-TS43-DL220 (1.09m) Smart
    WD4-TS43-DL220 (1.09m) Smart

 WD4-TS43-DL220

   - Screen size: 1.09m
   - Aspect ratio: 16:9
   - Resolution: 1920 x 1080
   - Viewing angle: H 1780 / V 1780
   - Contrast: 3000:1
​



    Tk. 39,400

Basic Information :
Product Type
                        Smart LED TV
Brightness(Typical)                            250 nits
Power Supply                    AC 110V-240V 50/60Hz
Maximum Power Consumption                             75W
Standby Power Consumption                          < 0.5 W
Hardware Configuration :
CPU                       ARM Cortex-A53 quad core
CPU Speed                               804MHz
RAM                                 1GB
ROM                                  8GB
GPU                           dual core Mali450
Software Configuration :
Operating System                            Android 7.0
Pre Installed App YouTube, Eshare, Aptoide TV, Airplay, Browser, File Browser, TV Clean (Screen  Mirroring Performance can vary upon device to device)
Display:
Screen size                                   1.09 m
Display Device                                    LCD
Backlight Unit                                   DLED
Resolution                             1920 X 1080
Aspect Ratio                                   16:9
Viewing Angle                         H 178° / V 178°
Contrast Ratio                                  3000:1
Color Resolution                                  16.7 M
Refresh Rate                                   60 Hz
Sound :
Audio Power Output (THD)                              2 X 8 Watt
Sound Mode                   User, Standard, Movie, Music
Sound Control                        2 Ch Speaker System
Input & Output Ports :
Analog Ports:
RF/ATV
                                   Yes
YPbPr                                    1
YPbPr Audio In                                    1
VGA                                    1
PC Audio IN                                    1
Line OUT                                  Yes
3.5 mm Audio OUT                                    1
Digital Ports:
HDMI 1.4                                    3
HDMI ARC / CEC                                  Yes
USB 2.0                                    2
Digital Audio OUT (Optical)                                    1
MicroSD Slot                                 No
Connectivity :
WiFi                                 Yes
LAN                                 Yes
Display Share         Eshare (Screen Mirroring Performance can vary upon device to device)
Wifi hotspot                                 Yes
TV System :
Video system           AVI; MP4; TS / TRP; MPG; MKV; MOV; DAT; VOB; RM / RMVB
Audio            MP3; WAV; MKA
Image             JPG/ JPEG/ BMP/ PNG
Text                               TXT
Accessory :
User manual                              Yes
Remote control                              Yes
Remote control Battery                              Yes
Wall Hanger Set                              Yes
Dimensions & Weight :
TV with Stand (L × W × H)                      970 mm x 270 mm x 630 mm
TV without Stand (L × W × H)                      970 mm x 80 mm x 570 mm
TV Shipping dimensions (L × W × H)                      1100 mm x 172 mm x 715 mm
TV with Stand Weight                                   7.3 KG
TV without Stand Weight                                   6.90 KG
TV Shipping Weight                                   10.6 KG
Loading :
40 HQ Container
                            Approx. 414 Pcs
40 GP Container
                            Approx. 414 Pcs
20 GP Container
                            Approx. 201 Pcs


​Warranty Information:

- TV Replacement Guarantee : 6 months (Condition Applicable)
- LED Panel: 4 Years
- Spare Parts: 2 Years
- Free Service: 5 Years


Note: This warranty does not cover any damage due to accident, electricity fault, natural causes or negligence. And Authority keeps the power to change, expend, correction, stop or cancel the warranty period without any prior notice.


SOP:
SOP for Smart Television :
App downloading procedure for Walton Smart TV

Basic Specification
Type LED
Screen Size 1.0922 meter
Resolution 1920X1080
Aspect Ratio 16:9,4:3
Viewing Angle H 178' / V 178'
Contrast Ratio 1000:1
Comb Filter 3D
Noise Reduction 3D
Video System PAL/NTSC
Sound System BG/D/K/I
